Ford Excursion I (1999-2005) 2 2 left tail lamps right tail lamps Wiring diagram
This page shows the only wiring diagram for the component.2 2 left tail lamps right tail lamps, which is found in the car Ford Excursion I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 2 left tail lamps right tail lamps (1 of 1)
2 2 LEFT TAIL LAMPS RIGHT TAIL LAMPS
6.0L
6.0L 1 2
AUXILIARY RELAY BOX 4 (EXCEPT 6.0L) (AT LEFT REAR SIDE OF ENGINE COMPARTMENT)
AUXILIARY RELAY BOX 5 (6.0L) (AT LEFT REAR SIDE OF ENGINE COMPARTMENT)
BACK-UP LAMPS CIRCUIT
BATTERY CHARGE TRAILER TOW RELAY
BLK WIRE
BLK/LT GRN WIRE
BLK/PNK WIRE
BRN WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LOWER LEFT SIDE OF DASH) FUSE 6
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/ORG WIRE
EXCEPT 6.0L
FUSE 115
FUSE 38
HOT AT ALL TIMES
HOT IN
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP TURN LAMP
LEFT TURN TRAILER TOW RELAY
LT GRN WIRE
LT GRN/ORG WIRE
MICROPROCESSOR
ORG/ WIRE
ORG/LT BLU WIRE
PARK LAMP RELAY
PARKING LAMP TRAILER TOW RELAY
REVERSING LAMP TRAILER TOW RELAY
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/STOP TURN LAMP
RIGHT TURN TRAILER TOW RELAY
RUN WIRE
TAN/WHT WIRE
TRAILER TOW CONNECTOR (4 PIN)
TRAILER TOW CONNECTOR (7 PIN)
VEHICLE SECURITY MODULE (VSM) (BEHIND LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> 2 2 LEFT TAIL LAMPS RIGHT TAIL LAMPS
