Ford Escort V facelift 2 (1995-2002) Charging circuit

1 12 11 11 (ESCORT) BATTERY BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BLU WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) CHARGE INDICATOR 100 OHMS FUEL INJECTION FUSE GENERATOR GRN WIRE HOT IN RUN OR START INSTRUMENT CLUSTER MAIN FUSE METER FUSE ORG/ WIRE POWER DISTRIBUTION STARTER ASSEMBLY WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
