Shift interlock circuit for Ford Escort V facelift 2 (1995-2002)
Shift interlock circuit
BLK WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DEACTIVATOR SWITCH
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
JOINT CONNECTOR 8
LOCKED
METER FUSE
NCA WIRE
PARK SENSE SWITCH (BELOW FRONT OF CENTER CONSOLE)
RELAY A
RELAY B
RELAY C
ROOM FUSE
SHIFT LOCK ACTUATOR (BELOW FRONT OF CENTER CONSOLE)
STOP FUSE
UNLOCKED
