Back-up lamps circuit for Ford Escort V facelift 2 (1995-2002)

Back-up lamps circuit

Get access

A/T BLK WIRE BLK/WHT WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) ENGINE FUSE HOT IN START OR RUN JOINT CONNECTOR JOINT CONNECTOR 9 M/T METER FUSE NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (BELOW CENTER OF DASH) RED/GRN WIRE REVERSING/ UPSHIFT SWITCH (ON LOWER FRONT OF TRANSAXLE) RIGHT REVERSING LAMP LEFT REVERSING LAMP SEDAN TRANSMISSION RANGE (TR) SENSOR WAGON
