Anti-lock brake circuits for Ford Escort V facelift 2 (1995-2002)

ABS FUSE ABS INDICATOR ABS MAIN RELAY (LEFT FRONT CORNER OF ENGINE COMPT, NEAR HORN) ABS RELAY CTRL AIR COND FUSE ANTI-LOCK BRAKE CONTROL MODULE (ON FLOOR, UNDER PASSENGER'S SEAT) ANTI-LOCK BRAKE INDICATOR ANTI-THEFT SYSTEM BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, ABOVE WHEELWELL) BLK WIRE BLK/PNK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRAKE PEDAL POSITION (BPP)SWITCH (TOP OF BRAKE PEDAL SUPPORT) BRN WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) STOP FUSE COUPE SDN/WGN 6 10 DATA LINK CONN GROUND GROUND DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DEACTIVATOR SWITCH (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/WHT WIRE GROUND POWER (ST/RUN) GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN OR START HYDRAULIC CONTROL UNIT (LEFT REAR OF ENGINE COMPARTMENT, BEHIND BATTERY) HYDRAULIC PUMP MOTOR INSTRUMENT CLUSTER JOINT CONNECTOR 1 JOINT CONNECTOR 5 LEFT FRONT DUMP VALVE LEFT FRONT SOLENOID VALVE LEFT REAR ANTI-LOCK BRAKE SENSOR (ON WHEEL ASSY) LEFT REAR SOLENOID VALVE LFT FRT ANTI-LOCK RT FRT ANTI-LOCK LFT RR ANTI-LOCK RT RR ANTI-LOCK LT GRN/BLK WIRE METER FUSE NCA WIRE ORG/ WIRE ORG/BLU WIRE PNK WIRE PNK/BLU WIRE PNK/GRN WIRE RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT DUMP VALVE RIGHT FRONT SOLENOID VALVE RIGHT REAR ANTI-LOCK BRAKE SENSOR (ON WHEEL ASSY) RIGHT REAR DUMP VALVE RIGHT REAR SOLENOID VALVE LEFT REAR DUMP VALVE SDN/WGN COUPE SUPPLEMENTAL RESTRAINTS SYSTEM VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/RED WIRE
