Ford Escort V facelift 2 (1995-2002) left/right select switch wiring diagram
This page shows the only wiring diagram for the component.left/right select switch, which is found in the car Ford Escort V facelift 2 (1995-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left/right select switch wiring diagram (1 of 1)
BLK WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
EXTERIOR REAR VIEW MIRROR SWITCH
HOT IN ACCY OR RUN
J/C 7 (RIGHT SIDE OF DASH)
L/R MOTOR
LEFT EXTERIOR REAR VIEW MIRROR
LEFT/RIGHT SELECT SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
MIRROR OR RADIO FUSE
NCA WIRE
RIGHT EXTERIOR REAR VIEW MIRROR
UP DN
UP DN DIRECTIONAL CONTROL SWITCH
UP/DN MOTOR
UP/DN MOTOR L/R MOTOR
Go to component -> Power mirror circuit -> LEFT/RIGHT SELECT SWITCH
