Interval wiper/washer circuit for Ford Escort V facelift (1991-1996)
Interval wiper/washer circuit
BLK WIRE
BLU WIRE
BLU/RED WIRE
DK BLU WIRE
DK BLU/YEL WIRE
GROUND
HOT IN RUN
I/P FUSE BLOCK
INT ON OFF LO
INTER- VAL RELAY
INTERVAL RHEOSTAT
JOINT CONNECTOR (NEAR LEFT HEADLIGHT)
JOINT CONNECTOR (RIGHT FENDER APRON)
LO INT
MULTI- FUNCTION SWITCH
NCA WIRE
OFF
ORG/ WIRE
PARK
RED WIRE
RUN WIRE
SOLID STATE
WASHER SWITCH OFF
WHT WIRE
WIND- SHIELD WASHER PUMP MOTOR
WIND- SHIELD WIPER MOTOR
WIPER FUSE
WIPER SWITCH
