Power door lock circuit for Ford Escort V facelift (1991-1996)
Power door lock circuit
BLK WIRE
DK BLU/RED WIRE
DK GRN WIRE
DOOR LOCK FUSE
DOOR LOCK/ UNLOCK RELAY (BEHIND LEFT SIDE OF I/P, NEAR COWL)
HOT AT ALL TIMES
I/P FUSE BLOCK
LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK MOTOR
LIFT- GATE LOCK MOTOR
LOCK
ORG/ WIRE
RED WIRE
RIGHT FRONT DOOR LOCK MOTOR
RIGHT REAR DOOR LOCK MOTOR
ROOM FUSE
SOLID STATE
UNLOCK
WAGON ONLY
WHT WIRE
