Headlamps/fog lamps circuit, without drl for Ford Escort V facelift (1991-1996)
Headlamps/fog lamps circuit, without drl
BLK WIRE
BLK/RED WIRE
BRN/YEL WIRE
DIMMER SWITCH
DK BLU/YEL WIRE
DK GRN/YEL WIRE
ENGINE COMPARTMENT FUSE BLOCK
FLASH TO PASS SW
FOG LIGHT SWITCH
HEAD FUSE
HEADLAMP RELAY
HI BEAM INDICATOR
HI LO
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT FOG LIGHT
LO HI LEFT HEADLIGHT
LO RIGHT HEADLIGHT
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
OFF
OFF HEAD
PARK
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
WHT WIRE
WHT/RED WIRE
