Ford Escape IV (2019-2024) Charging circuit

2.0L TURBO BATTERY BATTERY MONITORING SENSOR BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM GENERATOR GRN/BLU WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) INSTRUMENT PANEL CLUSTER (IPC) MODULE MEGA FUSE POWERTRAIN CONTROL MODULE (PCM) RED WIRE STARTER MOTOR VIO/BRN WIRE VIO/WHT WIRE WHT WIRE WHT/GRN WIRE
