Ford Escape IV (2019-2024) w/o passenger door module Wiring diagram
This page shows the only wiring diagram for the component.w/o passenger door module, which is found in the car Ford Escape IV (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o passenger door module (1 of 1)
2.5L PLUG-IN HYBRID
ALL WHEEL DRIVE (AWD) MODULE SHIELD
BLK WIRE
BLK/WHT WIRE
CHARGE PORT
FUEL PUMP CONTROL MODULE
FUEL PUMP, SENDER UNIT SHIELD
GRN WIRE
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PASSENGER DOOR MODULE (PDM)
PASSENGER DOOR WINDOW CONTROL SWITCH
POWER TRANSFER UNIT SHIELD
RIGHT EXTERIOR MIRROR
RIGHT FRONT DOOR LATCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP
RIGHT FRONT SEAT BACKREST HEATER MAT
RIGHT FRONT SEAT CONTROL SWITCH
RIGHT REAR DOOR LATCH
RIGHT REAR WINDOW CONTROL SWITCH
RIGHT SEAT BELT BUCKLE SWITCH
RIGHT SEAT TRACK POSITION SENSOR
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDM)
VIO WIRE
W/ AMBIENT LIGHTING
W/ POWER FOLDING MIRROR
W/O DOOR MODULE
W/O PASSENGER DOOR MODULE
W/O POWER FOLDING MIRROR
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (5 of 6) -> W/O PASSENGER DOOR MODULE
