Ford Escape IV (2019-2024) power liftgate release switch Wiring diagram
This page shows the only wiring diagram for the component.power liftgate release switch, which is found in the car Ford Escape IV (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power liftgate release switch (1 of 1)
0-POS SIG SWITCH
BLK/GRN WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CINCH MOTOR
GRY/VIO WIRE
GRY/YEL WIRE
HEADLAMP SWITCH
LEFT LIFTGATE OBSTACLE DETECTION STRIP
LIFTGATE LATCH/UNLATCH ASSEMBLY
LIFTGATE RELEASE SWITCH
NCA WIRE
POWER LIFTGATE DETENT SWITCH
POWER LIFTGATE RELEASE SWITCH
POWER LIFTGATE SWITCH
PRIMARY RATCHET SWITCH
RIGHT LIFTGATE OBSTACLE DETECTION STRIP
SECONDARY RATCHET SWITCH
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Power liftgate circuit (2 of 2) -> POWER LIFTGATE RELEASE SWITCH
