Ford Escape IV (2019-2024) pass htd st ele Wiring diagram
This page shows the only wiring diagram for the component.pass htd st ele, which is found in the car Ford Escape IV (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass htd st ele (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRV HTD ST ELE
DRV HTR FEED
DRV SEAT NTC SNS
FUSE 39
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
HOT AT ALL TIMES
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CUSHION HEATER MAT
MS CAN +
NCA WIRE
PASS HTD ST ELE
PASS HTR FEED
PASS SEAT NTC SNS
RIGHT FRONT SEAT BACKREST HEATER MAT
RIGHT FRONT SEAT CUSHION HEATER MAT
SIG RTN
VIO/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Heated seats circuit -> PASS HTD ST ELE
