Ford Escape IV (2019-2024) fuse 51 Wiring diagram
This page shows the only wiring diagram for the component.fuse 51, which is found in the car Ford Escape IV (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 51 (1 of 1)
ANTENNA WAVE TRAP
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CASE HEATER GND GRID
COMPUTER DATA LINES SYSTEM
FUSE 133
FUSE 50
FUSE 51
GRN/BRN WIRE
HEATED MIRROR/ REAR WINDOW DEFROST RELAY
HEATED REAR WINDOW ELEMENT
HEATED WIPER PARK
HEATED WIPER PARK RELAY
HOT AT ALL TIMES
LEFT EXTERIOR MIRROR
LIN 10
MICRO -
NCA WIRE
PWR
RIGHT EXTERIOR MIRROR
VCOIL 1
VCOIL 2
VIO/GRY WIRE
VPWR
WHT WIRE
YEL/ORG WIRE
Go to component -> Defoggers circuit, w/o door module -> FUSE 51
