Ford Escape IV (2019-2024) eghr outlet temperature sensor Wiring diagrams

This page contains all the electrical diagrams for the component. eghr outlet temperature sensor, in which he is found in the car Ford Escape IV (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram eghr outlet temperature sensor (1 of 3)

Wiring diagram eghr outlet temperature sensor for Ford Escape IV (2019-2024) (1 of 3)

Get access

2.0L TURBO 2.5L HYBRID 2.5L PLUG-IN HYBRID BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRN (OR BRN/GRN) WIRE BLU/GRN WIRE BLU/GRY WIRE CABIN HEATER COOLANT PUMP CHT CHT 2 COMPUTER DATA LINES SYSTEM CPC CYLINDER HEAD TEMPERATURE (CHT) SENSOR ECT EGHR OUTLET TEMPERATURE SENSOR ENGINE CONTROLS ENGINE COOLANT BYPASS VALVE ENGINE COOLANT TEMPERATURE (ECT) SENSOR EXCEPT 2.0L TURBO FC-V GRN/BLU WIRE GRY/ORG WIRE GRY/YEL WIRE ISP-R POWERTRAIN CONTROL MODULE (PCM) PWM PWR PWR GND RTN S178 (1.5L TURBO) S156 (2.0L TURBO) SIGRTN SYSTEM VBATT VIO/BRN WIRE VIO/GRN WIRE VREF WHT WIRE YEL WIRE YEL/GRN (OR BRN/GRN) WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component -> Cooling fan circuit (2 of 2) -> EGHR OUTLET TEMPERATURE SENSOR

Wiring diagram eghr outlet temperature sensor (2 of 3)

Wiring diagram eghr outlet temperature sensor for Ford Escape IV (2019-2024) (2 of 3)

Get access

2.5L HYBRID 2.5L PLUG-IN HYBRID ACTIVE GRILLE SHUTTER AMBIENT AIR TEMPERATURE (AAT) SENSOR BLK WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE CABIN HEATER COOLANT PUMP EGHR INLET TEMPERATURE SENSOR EGHR OUTLET TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE (ECT) SENSOR ENGINE COOLING VALVE EVAP LEAK DETECTION CONTROL MODULE EXHAUST HEAT EXCHANGER BYPASS VALVE FUEL FILLER DOOR LOCK SOLENOID FUEL TANK PRESSURE (FTP) SENSOR GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE ORG/BLK WIRE PWM IN PWM OUT PWR RED WIRE REFUELING VALVE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT/BLU WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> Wiring diagram engine performance 2.5l hybrid (2 of 13) -> EGHR OUTLET TEMPERATURE SENSOR
