Ford Escape IV (2019-2024) computer data lines system cooling fans system Wiring diagram
This page shows the only wiring diagram for the component.computer data lines system cooling fans system, which is found in the car Ford Escape IV (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines system cooling fans system (1 of 1)
AAT
ACCELERATOR PEDAL POSITION (APP) SENSOR
ACP
AMBIENT AIR TEMPERATURE (AAT) SENSOR
AUTO-START-STOP ACCUMULATOR
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRN/BLU WIRE
BRN/RED WIRE
CANV
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM
COOLING FANS SYSTEM
CPC
EVAPCP
EVAPSV
FC-V
FPRC
FPRP
FTP
FUSE 22
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR
MAP
MEGA FUSE
MICRO -
PCM WAKE UP (FET)
PCMRC
POWERTRAIN CONTROL MODULE (PCM)
RTN
SIGRTN-C
SMR
SST DN
SST UP
STARTING/CHARGING SYSTEM
TCM CAN -
TRANSMISSIONS SYSTEM
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VREF
VREF 16 17
WHT WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (1 of 8) -> COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM
