Ford Escape IV (2019-2024) central lock relay Wiring diagrams

This page contains all the electrical diagrams for the component. central lock relay, in which he is found in the car Ford Escape IV (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram central lock relay (1 of 4)

Wiring diagram central lock relay for Ford Escape IV (2019-2024) (1 of 4)

Get access

AMB LTG (FET) BLK/WHT WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/GRN WIRE BRN/YEL WIRE CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY CHMSL LP (FET) LIN 08 DECKLID/ LIFTGLASS AJAR DECKLID/LIFTGATE RELEASE (FET) DEFOGGER SYSTEM DEMAND LP/ BATT SAVE (FET) DISCRATE VSPD (HB) DOOR LOCK DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, SHIFT INTERLOCK SYSTEMS DOOR UNLOCK DOUBLE/ AUX LOCK RELAY (NOT USED) RR STOP POS LPS (FET) DRIVER/ FUEL FLAP UNLOCK RELAY EXT 1 ANT HI (HB) EXT 2 ANT HI (HB) EXT 2 ANT LO (HB) GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM INSTRUMENT CLUSTER, DOOR LOCKS, ANTI-THEFT SYSTEMS INT 1 ANT HI (HB) RTN INT 1 ANT LO (HB) INT 2 ANT HI (HB) EXT 1 ANT LO (HB) INT 2 ANT LO (HB) INT LTG (FET) KEYPAD A KEYPAD B KEYPAD C KEYPAD ILLUM (FET) LF DOOR AJAR LF TURN OUTAGE LIN 06 LIN 10 LOGIC GROUND LR DOOR AJAR LR POS LPS (FET) LIN 02 LR STOP POS LPS (FET) ENS LR TURN LPS (FET) MICRO - NAVIGATION SYSTEM PARK LAMPS (FET) POWER TOPS SYSTEM POWER TOPS, POWER DISTRIBUTION SYSTEMS POWER WINDOWS SYSTEM PROTECT 1 ANT HI (HB) PROTECT 1 ANT LO (HB) REV LPS (FET) RF DOOR AJAR RR DOOR AJAR RR POS LPS (FET) RR TURN LPS (FET) SUPPLEMENTAL RESTRAINTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE VREF WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> Body control modules circuit (2 of 2) -> CENTRAL LOCK RELAY

Wiring diagram central lock relay (2 of 4)

Wiring diagram central lock relay for Ford Escape IV (2019-2024) (2 of 4)

Get access

AJAR BLK/VIO WIRE BLK/WHT WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE CENTER CONSOLE CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY DOOR STATUS DOUBLE/ AUX LOCK RELAY DRIVER/ FUEL FLAP UNLOCK RELAY FROM BACK LTG (FET) (DIAGRAM 3 OF 5) FUSE 13 FUSE 5 FUSE 7 GEAR SHIFT MODULE (GSM) GRN/VIO WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE HOT AT ALL TIMES LEFT FRONT DOOR LATCH MICRO - RIGHT FRONT DOOR LATCH UNLOCK W/ DOOR MODULE W/O DOOR MODULE WHT WIRE WHT/RED WIRE YEL/RED WIRE

Go to component -> Forced entry circuit (2 of 5) -> CENTRAL LOCK RELAY

Wiring diagram central lock relay (3 of 4)

Wiring diagram central lock relay for Ford Escape IV (2019-2024) (3 of 4)

Get access

2.5L HYBRID 2.5L PLUG-IN HYBRID AIR CONDITIONING CONTROL MODULE (ACCM) BACK LTG (FET) BLK/VIO WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY CHILD LOCK RELAY COMPUTER DATA LINES SYSTEM DEMAND LP/ BATT SAVE (FET) DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER CONTROL MODULE DOUBLE/ AUX LOCK RELAY DRIVER/FUEL FLAP UNLOCK RELAY ENGINE CONTROLS SYSTEM FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 9) FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 9) FROM LF LOW BEAM (FET) (DIAGRAM 7 OF 9) FUSE 13 FUSE 18 FUSE 5 GRN/BLU WIRE GRN/BRN WIRE HIGH VOLTAGE BATTERY JUNCTION BOX HV BATT - INT LTG (FET) KEYPAD ILLUM (FET) MICRO - ORG/ WIRE ORG/GRN WIRE ORG/GRY WIRE RED WIRE SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDM) VBATT WAKEUP WHT WIRE WHT/GRN WIRE WHT/RED WIRE WIRELESS ACCESSORY CHARGING MODULE (WACM) WIRELESS CHARGE SIGNAL OUTPUT (FET) YEL/RED WIRE

Go to component -> Power distribution circuit (8 of 9) -> CENTRAL LOCK RELAY
