Ford Escape III facelift (2015-2019) left lower steering wheel multi-function switch Wiring diagrams

AUTOMATIC A/C AUXILIARY POWER POINT BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLOWER MOTOR CONTROL MODULE BLU WIRE BODY CONTROL MODULE (BCM) CLOCK SPRING (STEERING COLUMN) DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER MODULE DRIVER DOOR MODULE (DDM) DRIVER DOOR WINDOW CONTROL SWITCH DRIVER SEAT MODULE (DSM) DRIVER SIDE FRONT SEAT CONTROL SWITCH ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE FLOOR CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP FLOOR SHIFTER ILLUMINATION FRONT CONTROLS INTERFACE MODULE (FCIM) FRONT POWER OUTLET SOCKET GRN WIRE GRY WIRE HEAD-UP DISPLAY (HUD) MODULE HEADLAMP SWITCH HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE HORN SWITCH INSTRUMENT PANEL AMBIENT LIGHTING LAMP INSTRUMENT PANEL CLUSTER (IPC) MODULE INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY KEYLESS ENTRY KEYPAD LEFT EXTERIOR MIRROR LEFT FRONT DOOR LATCH RELEASE MOTOR LEFT FRONT DOOR LOCK SWITCH LEFT FRONT HEATED SEAT MODULE LEFT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP LEFT LOWER STEERING WHEEL MULTI-FUNCTION SWITCH LEFT UPPER STEERING WHEEL MULTI-FUNCTION SWITCH LOW VOLTAGE DIRECT CURRENT/DIRECT CURRENT (DC/AC) CONVERTER MANUAL A/C NCA WIRE PARKING BRAKE SWITCH PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR/ DEFROST SWITCH PASSENGER DOOR MODULE (PDM) PASSENGER DOOR WINDOW CONTROL SWITCH PASSENGER SIDE FRONT SEAT CONTROL SWITCH REAR FOOTWELL LAMP REAR PASSENGER POWER OUTLET SOCKET REMOTE FUNCTION ACTUATOR (RFA) MODULE RIGHT EXTERIOR MIRROR RIGHT FRONT DOOR LATCH RELEASE MOTOR RIGHT FRONT DOOR LOCK SWITCH RIGHT FRONT HEATED SEAT MODULE RIGHT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP RIGHT LOWER STEERING WHEEL MULTI-FUNCTION SWITCH RIGHT UPPER STEERING WHEEL MULTI-FUNCTION SWITCH ROOF OPENING PANEL MODULE STEERING ANGLE SENSOR MODULE (SASM) STEERING WHEEL) TRANSMISSION CONTROL SWITCH (TCS) VIO WIRE W/ 8 INCH DISPLAY W/ AMBIENT LIGHTING W/ INTELLIGENT ACCESS W/ MEMORY W/O DOOR MODULES W/O MEMORY W/O SONY SOUND WHT WIRE

BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) CLOCK- SPRING COMPUTER DATA LINES SYSTEM FLOOR SHIFTER ILLUMINATION FRONT INTERIOR LAMP FUSE 24 GRN WIRE GRN/RED WIRE GRN/VIO WIRE HEADLAMP SWITCH HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HS CAN+ ILLUM INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY IP SW ILLUM KEYLESS ENTRY KEYPAD KEYPAD ILLUM LEFT FRONT DOOR LOCK SWITCH LEFT LOWER STEERING WHEEL MULTI-FUNCTION SWITCH LEFT UPPER STEERING WHEEL MULTI-FUNCTION SWITCH LOGIC GND MEGA FUSE 4 MEGA FUSE 9 MICRO - NCA WIRE ORG/ WIRE OVERHEAD CONSOLE PARKING BRAKE SWITCH PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR/ DEFROST SWITCH PWR GND RED WIRE RIGHT FRONT DOOR LOCK SWITCH RIGHT LOWER STEERING WHEEL MULTI-FUNCTION SWITCH RIGHT UPPER STEERING WHEEL MULTI-FUNCTION SWITCH START/STOP SWITCH STEERING COLUMN CONTROL MODULE (SCCM) STEERING COLUMN) SW ILLUM TRANSMISSION CONTROL SWITCH (TCS) VBATT VIO/BRN WIRE VIO/GRY WIRE VIO/RED WIRE W/ INTELLIGENT ACCESS W/ MEMORY W/O MEMORY W/O SUNVISOR ILLUMINATION W/ SUNVISOR ILLUMINATION W/ ROOF OPENING PANEL W/O SONY SOUND WHT WIRE WHT/BLU WIRE WHT/GRN WIRE
