Ford Escape III facelift (2015-2019) externally controlled variable displacement compressor Wiring diagram
This page shows the only wiring diagram for the component.externally controlled variable displacement compressor, which is found in the car Ford Escape III facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram externally controlled variable displacement compressor (1 of 1)
1.5L TURBO 2.0L TURBO 2.5L
2.0L TURBO
2.5L
A/C CLUTCH RELAY
AC OUTLET
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
BLK WIRE
BLK/GRN WIRE
BLU/RED WIRE
BRN/RED WIRE
CABIN HEATER COOLANT PUMP
CHARGE AIR COOLER (CAC) PUMP
DIRECT CURRENT/ALTERNATING CURRENT (DC/AC) INVERTER
ENGINE COOLING FAN RELAY
EXTERNALLY CONTROLLED VARIABLE DISPLACEMENT COMPRESSOR
FROM FUSE 33 (DIAGRAM 5 OF 7)
FROM FUSE 36 (DIAGRAM 2 OF 7)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 7)
FUSE 20
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 30
FUSE 32
FUSE 34
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
LUGGAGE COMPARTMENT POWER OUTLET SOCKET
OIL PRESSURE CONTROL SOLENOID VALVE
ORG/ WIRE
PARKING AID MODULE (PAM)
REAR GATE TRUNK MODULE (RGTM)
REAR PASSENGER POWER OUTLET SOCKET
REAR WINDOW DEFROST RELAY
RED WIRE
TELEMATIC CONTROL UNIT MODULE (TCU)
TRANSMISSION FLUID COOLER COOLANT CONTROL VALVE
TRANSMISSION FLUID HEATER COOLANT CONTROL VALVE
TURBOCHARGER BYPASS VALVE (TCBY)
TURBOCHARGER WASTEGATE REGULATING VALVE SOLENOID (TCWRVS)
VIO/BRN (OR GRY) WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
W/ SONY
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Power distribution circuit (7 of 7) -> EXTERNALLY CONTROLLED VARIABLE DISPLACEMENT COMPRESSOR
