Power windows circuit, without door module & rear power window for Ford Escape III (2012-2015)
Power windows circuit, without door module & rear power window
1 7 UP DN
BATTERY JUNCTION
BLK/GRN WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DRIVER SIDE POWER WINDOW MOTOR
FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN/ORG WIRE
GRY WIRE
GRY/YEL WIRE
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
LEFT FRONT
MASTER WINDOW CONTROL SWITCH
MIRROR SWITCHES
MIRRORS SYSTEM
PASSENGER SIDE POWER
PASSENGER SIDE WINDOW CONTROL SWITCH
PWR
RIGHT FRONT SWITCH
RIGHT FRONT SWITCH UP
VIO/RED WIRE
WHT WIRE
WHT/ORG WIRE
WINDOW MOTOR
YEL/ORG WIRE
YEL/VIO WIRE
