Power mirrors circuit, without door module for Ford Escape III (2012-2015)
Power mirrors circuit, without door module
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/VIO WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DRIV L/R
DRIV U/D
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 25
GRY WIRE
GRY/YEL WIRE
HOT W/ IGNITION RELAY ENERGIZED
LEFT EXTERIOR REAR VIEW MIRROR
MASTER WINDOW CONTROL SWITCH
NCA WIRE
PASS L/R
PASS U/D
PWR
RETURN
RIGHT EXTERIOR REAR VIEW MIRROR
WHT/ORG WIRE
YEL/VIO WIRE
