Ford Escape III (2012-2015) Rear camera circuit

1 2 3 4 5 6 7 8 GND MS CAN + MS CAN - VPWR ACCESSORY PROTOCOL INTERFACE MODULE BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY BLK/ WIRE GRY WIRE GRY/ORG WIRE HOT W/ ACCESSORY RELAY ENERGIZED IMAGE PROCESSING MODULE B (IPM-B) (BEHIND LEFT QUARTERPANEL) LIN NCA WIRE PWR REAR JUNCTION BOX (RJB) (BEHIND RIGHT QUARTERPANEL) SHIELD VIDEO CAMERA (RIGHT CENTER OF LIFTGATE) VIDEO+ VIO/ORG WIRE WHT WIRE WHT/BLU WIRE
