Ford Escape III (2012-2015) reversing lamp wiring diagram
This page shows the only wiring diagram for the component.reversing lamp, which is found in the car Ford Escape III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
reversing lamp wiring diagram (1 of 1)
1.6L
2.0L
2.5L 2.0L 1.6L
20 17 18 TSS/ OSS/TR GND TR-P TSS/ OSS/TR VPWR
69 68 69 68 59 58 HS CAN+ HS CAN-
AUTO DIMMING INTERIOR MIRROR
BLK/WHT WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM
GRN/BRN WIRE
HOT AT ALL TIMES FUSE
HS HS CAN+ CAN-
LEFT REVERSING LAMP
MICRO -
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT)
RELAY
REVERSING LAMP
RIGHT REVERSING LAMP
TR GND
TRANSMISSIONS SYSTEM
TSS/ OSS/ 1 39 36 22 10 32 22 10 32 TR VPWR TR-P TSS/ OSS/
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Backup lamps circuit -> REVERSING LAMP
