Ford Escape III (2012-2015) pass canopy feed pass canopy rtn Wiring diagram

BATTERY JUNCTION BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COLLAPSIBLE STEERING COLUMN MODULE (ON STEERING COLUMN) DRIVER FRONT DOOR SIDE IMPACT SENSOR (FRONT OF DRIVER'S DOOR) DRIVER KNEE AIR BAG MODULE (LOWER LEFT SIDE OF DASH) DRIVER SAFETY BELT ANCHOR PRETENSIONER (BASE OF LEFT ''B" PILLAR) FUSE 37 BOX (BJB) (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/YEL WIRE HOT IN RUN OR START INPUT PASS SEAT POS SNS DRVR CANOPY FEED DRVR CANOPY RTN LEFT SIDE AIR CURTAIN MODULE (TOP OF LEFT "C" PILLAR) NCA WIRE PASS CANOPY FEED PASS CANOPY RTN PASS SIDE IM RTN PASS SIDE IM FEED DRVR SIDE IM FEED DRVR SIDE IM RTN PASSENGER FRONT DOOR SIDE IMPACT SENSOR (FRONT OF FRONT PASSENGER'S DOOR) PASSENGER SAFETY BELT ANCHOR PRETENSIONER (BASE OF RIGHT ''B" PILLAR) PASSENGER SAFETY BELT LOAD LIMITING RETRACTOR (BASE OF RIGHT "B" PILLAR) RESTRAINTS CONTROL MODULE (RCM) (UNDER CENTER CONSOLE) RIGHT SIDE AIR CURTAIN MODULE (TOP OF RIGHT "C" PILLAR) SHORTING BAR VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
