Ford Escape III (2012-2015) (park aid sensor wiring assembly, near breakout Wiring diagram
This page shows the only wiring diagram for the component.(park aid sensor wiring assembly, near breakout, which is found in the car Ford Escape III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (park aid sensor wiring assembly, near breakout (1 of 1)
1 13 5 18 MS CAN+ MS CAN- TURN LP VPWR MIRR GND
2 1 MS CAN + MS CAN -
2 13 VBATT GND
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 4
FUSE 5
FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY/ORG WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT EXTERIOR REAR VIEW MIRROR
LEFT FRONT AUXILIARY PARK LAMP (W/ HALOGEN, W/O FOG LAMPS)
LEFT FRONT PARKING LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP TURN LAMP
MS CAN - MS CAN +
NCA WIRE
PARK
PASSENGER DOOR MODULE (PDM)
REAR JUNCTION BOX (RJB) (BEHIND RIGHT QUARTERPANEL)
RED WIRE
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT FRONT AUXILIARY PARK LAMP (W/ HALOGEN, W/O FOG LAMPS)
RIGHT FRONT PARKING LAMP
RIGHT LICENSE PLATE LAMP
STOP
TRAILER/CAMPER ADAPTER CIRCUIT
TURN
TURN LP VPWR MIRR GND
VBATT GND
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
W/ REAR VIEW CAMERA
W/O REAR VIEW CAMERA
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> (PARK AID SENSOR WIRING ASSEMBLY, NEAR BREAKOUT
