Ford Escape III (2012-2015) fuse 40 fuse 43 fuse fuse wiring diagram
This page shows the only wiring diagram for the component.fuse 40 fuse 43 fuse fuse, which is found in the car Ford Escape III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fuse 40 fuse 43 fuse fuse wiring diagram (1 of 1)
1.6L
2.0L
2.0L 2.0L 1.6L 1.6L
2.5L
2.5L 2.0L EXCEPT EXCEPT 2.5L 2.0L
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
BRN/RED WIRE
CONTROL
EGR STEPPER MOTOR (2.5L)
ENGINE COOLING FAN RELAY
FROM FUSE 35 (DIAGRAM 1 OF 6) FUSE
FROM SPLICE
FUSE
FUSE 36
FUSE 40 FUSE 43 FUSE FUSE
FUSE 41 FUSE 38
FUSE 42
FUSE A/C CLUTCH RELAY
GRILLE SHUTTER ACTUATOR
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
IGNITION
IGNITION RELAY
LEFT FRONT WINDSHIELD WIPER MOTOR
MASTER WINDOW CONTROL SWITCH (W/O DOOR MODULES)
MICRO -
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
POWERTRAIN CONTROL MODULE (PCM)
REAR WINDOW WIPER MOTOR
RELAY
RIGHT FRONT WINDSHIELD WIPER MOTOR
RIGHT HEADLAMP ASSEMBLY
SOLENOID SOLENOID (EXCEPT 2.5L)
TO BODY CONTROL MODULE (BCM) (DIAGRAM 3 OF 6)
UNIVERSAL HEATED OXYGEN SENSOR
VARIABLE VARIABLE CAMSHAFT CAMSHAFT TIMING 12 TIMING 11
VIO/BRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (2 of 6) -> FUSE 40 FUSE 43 FUSE FUSE
