Ford Escape III (2012-2015) floor shifter illum Wiring diagram

1 3 ILLUM GND 1 5 7 VBATT LIN GND 4 2 ILLUM GND ASSEMBLY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH) CENTER STACK SWITCH COMPUTER DATA LINES SYSTEM DRIVER SIDE DOOR LOCK CONTROL SWITCH EXCEPT BASE FLOOR SHIFTER ILLUM FRONT INTERIOR/ MAP LAMPS ASSEMBLY (W/O ROOF OPENING PANEL) FUSE 24 GRN WIRE GRN/VIO WIRE HEADLAMP SWITCH HIGH CURRENT HOT AT ALL TIMES HS CAN+ ILLUM IP SW ILLUM KEYPAD ILLUM KEYPAD SWITCH ASSEMBLY LEFT FRONT INTERIOR/ MAP LAMPS ASSEMBLY (W/ ROOF OPENING PANEL) LEFT FRONT SEAT HEATER SWITCH LEFT LOWER STEERING WHEEL SWITCH LEFT UPPER STEERING WHEEL SWITCH 2 6 ILLUM GND LIN LOGIC GND MEGA FUSE 4 MEGA FUSE 9 MICRO - NCA WIRE ORG/ WIRE OVERHEAD CONSOLE SWITCH ASSEMBLY PASSENGER AIRBAG DEACTIVATION (PAD) INDICATOR/ DEFROST SWITCH PASSENGER SIDE DOOR LOCK CONTROL SWITCH PWR GND RED WIRE RIGHT FRONT SEAT HEATER SWITCH RIGHT LOWER STEERING WHEEL SWITCH RIGHT UPPER STEERING WHEEL SWITCH START/STOP SWITCH (W/ INTELLIGENT ACCESS) STEERING ANGLE SENSOR MODULE SW ILLUM VBATT VIO/BRN WIRE VIO/GRY WIRE VIO/RED WIRE W/ HEATED SEATS W/ MEMORY W/O MEMORY BASE W/ SONY SOUND W/O SONY SOUND WHT WIRE WHT/ BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
