Ford Escape III (2012-2015) fan ctrl variable Wiring diagram
This page shows the only wiring diagram for the component.fan ctrl variable, which is found in the car Ford Escape III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fan ctrl variable (1 of 1)
2.0L 1.6L TURBO TURBO
2.0L TURBO
2.5L
39 49 CHT SIGRTN
55 34 LIN FCV
59 58 69 68 HS CAN + HS CAN -
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRY WIRE
COMPUTER DATA LINES SYSTEM
CYLINDER HEAD TEMPERATURE SENSOR (2.5L) (TOP CENTER OF CYLINDER HEAD)
ECT
ELECTRONICS ENGINE COOLING FAN MOTOR (BEHIND RADIATOR)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (EXCEPT 2.5L)
ENGINE COOLING FAN RELAY
FAN CTRL VARIABLE
FUSE 34
FUSE 36
FUSE 8
GENERATOR (2.5L)
GRILLE SHUTTER ACTUATOR (BEHIND RIGHT SIDE OF FRONT GRILLE)
GRN/VIO WIRE
GRN/WHT WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LIN
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT)
PWR
SIGRTN
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Cooling fan circuit -> FAN CTRL VARIABLE
