Ford Escape III (2012-2015) engine grille cooling shutter fan motor actuator Wiring diagram
This page shows the only wiring diagram for the component.engine grille cooling shutter fan motor actuator, which is found in the car Ford Escape III (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine grille cooling shutter fan motor actuator (1 of 1)
1.6L
2.0L
2.5L 2.0L
2.5L 2.0L 1.6L
A/C COMPRESSOR CLUTCH FIELD COIL
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BATTERY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF
BATTERY MONITORING SENSOR
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRAKE FLUID HORN LEVEL SWITCH
BRAKE PEDAL POSITION (BPP) SWITCH
ELECTRIC BOOSTER HEATER
ENGINE COMPT)
ENGINE COOLING FAN RELAY
ENGINE GRILLE COOLING SHUTTER FAN MOTOR ACTUATOR
GRN WIRE
GRY WIRE
LEFT FRONT FOG LAMP
LEFT FRONT TURN LAMP
LEFT FRONT WINDSHIELD WIPER MOTOR
LEFT HEADLAMP ASSEMBLY
ORG/ WIRE
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT FOG LAMP
RIGHT FRONT TURN LAMP
RIGHT FRONT WINDSHIELD WIPER MOTOR
RIGHT HEADLAMP ASSEMBLY
VIO WIRE
W/ HALOGEN LAMPS
W/ INTELLIGENT ACCESS
WHT/VIO WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> ENGINE GRILLE COOLING SHUTTER FAN MOTOR ACTUATOR
