Backup lamps circuit, hybrid for Ford Escape II (2007-2012)
Backup lamps circuit, hybrid
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/VIO WIRE
ELECTROCHROMATIC REAR VIEW MIRROR
FUSE 28
FUSE 35
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT REVERSING LAMP
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM) (REAR CENTER OF FIREWALL)
REAR DEFROST RELAY
REARVIEW CAMERA DISPLAY MIRROR
REVERSE IN
REVERSE LAMP RELAY
RIGHT REVERSING LAMP
RLC
TRANSMISSION RANGE (TR) SENSOR
VIO WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
