Ford Escape II (2007-2012) right vanity mirror lamp on Wiring diagram
This page shows the only wiring diagram for the component.right vanity mirror lamp on, which is found in the car Ford Escape II (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right vanity mirror lamp on (1 of 1)
AJAR
AJAR LR DOOR
BACK- LIGHTING (FET)
BATTERY SAVER RELAY
BLK WIRE
BLK/GRY WIRE
BLU WIRE
CARGO LAMP
DATA LINK CONNECTOR (DLC)
DR 3 1 ON
DRIVER SIDE FRONT DOOR LOCK UNIT (REAR OF DRIVER'S DOOR)
EARLY PRODUCTION
FRONT INTERIOR LAMP
FRONT INTERIOR LAMP OFF DR
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FUSE
FUSE 10
FUSE 41
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY DELAY RELAY ENERGIZED
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHTING (FET)
LEFT REAR DOOR LOCK ACTUATOR (LEFT REAR DOOR)
LEFT VANITY MIRROR LAMP ON OFF OFF
LF DOOR
LIFTGATE
LIFTGATE AJAR SWITCH (BOTTOM CENTER OF LIFTGATE)
LIFTGATE GLASS AJAR SWITCH (CENTER OF LIFTGATE)
LOGIC
OFF
OFF OFF ON ON
OFF OFF ON ON DR
ON OFF
PASSENGER SIDE FRONT DOOR LOCK UNIT (REAR OF RIGHT FRONT DOOR)
PF DOOR AJAR
RIGHT REAR DOOR LOCK ACTUATOR (RIGHT REAR DOOR)
RIGHT VANITY MIRROR LAMP ON
RR DOOR
SMART JUNCTION BOX (SJB)
VIO/GRY WIRE
W/ ROOF W/O ROOF OPENING OPENING PANEL PANEL
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Courtesy lamps circuit, hybrid (1 of 2) -> RIGHT VANITY MIRROR LAMP ON
