Ford Escape II (2007-2012) master driver window side control door switch lock switch Wiring diagrams
This page contains all the electrical diagrams for the component. master driver window side control door switch lock switch, in which he is found in the car Ford Escape II (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
master driver window side control door switch lock switch wiring diagram (1 of 2)
2.5L
3.0L
ACCESSORY DELAY RELAY
ACCESSORY PROTOCOL INTERFACE MODULE
ALL LOCK, UNLOCK RELAY
AMBIENT AMBIENT LIGHTING LIGHTING SWITCH MODULE
BACK- LIFTGLASS LIFTGATE LIGHTING RELEASE (FET) LED (FET) RELAY
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BATTERY SAVER RELAY
BLU WIRE
BSI LOGIC ILLUM (FET) (FET)
CIRCUIT BREAKER 47
DATA LINK CONNECTOR (DLC)
DRIVER UNLOCK RELAY
FOG LAMP RELAY
FROM FUEL INJECTOR RELAY (DIAGRAM 1 OF 4)
FROM FUSE 14 (DIAGRAM 1 OF 4)
FROM FUSE 17 (DIAGRAM 2 OF 4)
FUEL FUEL FUEL INJECTOR INJECTOR INJECTOR
FUEL FUEL INJECTOR INJECTOR
FUEL INJECTOR
FUSE 10 FUSE 17
FUSE 15
FUSE 18 FUSE 23
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 27
FUSE 41
FUSE 5
FUSE 6
FUSE 7
FUSE 8 FUSE 3
FUSE 9
GRN WIRE
HIGH BEAM RELAY
HORN RELAY
HVAC MODULE
INTERIOR LIGHTING (FET)
KEYPAD
LEFT LOW BEAM (FET)
LF TURN LAMP (FET)
LOGIC
LR STOP/ TURN LAMP (FET)
MASTER DRIVER WINDOW SIDE CONTROL DOOR SWITCH LOCK SWITCH
PARK LAMP RELAY
PASSENGER DRIVER HEATED HEATED SEAT RELAY SEAT RELAY
PASSENGER SIDE DOOR LOCK SWITCH
POWERTRAIN CONTROL MODULE
POWERTRAIN CONTROL MODULE (PCM)
REAR VIEW CAMERA DISPLAY MIRROR
RED WIRE
RF TURN LAMP (FET)
RIGHT LOW BEAM (FET)
ROOF AUTO- OPENING DIMMING PANEL INTERIOR MODULE MIRROR
ROOF MULTI- OPENING MEDIA PANEL INSIDE SWITCH MIRROR UNIT
RR STOP/ TURN LAMP (FET)
SEAT)
TO FUSE 22 (DIAGRAM 4 OF 4)
TO FUSE 27 (DIAGRAM 2 OF 4)
TO IGNITION SWITCH (DIAGRAM (UNDER 3 OF 4) DRIVER'S SEAT)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 4) -> MASTER DRIVER WINDOW SIDE CONTROL DOOR SWITCH LOCK SWITCH
master driver window side control door switch lock switch wiring diagram (2 of 2)
A/C CYCLING SWITCH
ABS TEST CONNECTOR
ACCESSORY DELAY RELAY
AIR CONDITIONING CONTROL MODULE
ALL LOCK, UNLOCK RELAY
AMBIENT LIGHTING MODULE
AMBIENT LIGHTING SWITCH
BACK LIGHTING LED (FET)
BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT)
BATTERY SAVER RELAY
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BSI KEYPAD LOGIC ILLUM (FET) (FET)
CIRCUIT BREAKER 47
COOLING FAN HIGH SPEED RELAY
COOLING FAN RELAY
DATA LINK CONNECTOR (DLC)
DRIVER HEATED SEAT RELAY
DRIVER UNLOCK RELAY
EGR STEPPER MOTOR
EVAPORATIVE HEATED EMISSION OXYGEN (EVAP) CANISTER SENSOR PURGE VALVE
FOG LAMP RELAY
FROM FUSE 14 (DIAGRAM 1 OF 5)
FROM FUSE 17 (DIAGRAM 3 OF 5)
FROM FUSE 26 COOLING FAN (DIAGRAM LOW SPEED 2 OF 5) RELAY
FRONT STORAGE TRAY LAMP
FUEL VAPOR VENT VALVE
FUSE
FUSE 10
FUSE 17
FUSE 18 FUSE 15
FUSE 20
FUSE 21
FUSE 22
FUSE 24
FUSE 25
FUSE 27
FUSE 27 FUSE 23
FUSE 28
FUSE 41
FUSE 5
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR
HEATER PUMP RELAY
HIGH BEAM RELAY
HORN RELAY
HVAC MODULE
INTERIOR LIGHTING (FET)
LEFT LOW BEAM (FET)
LF TURN LAMP (FET)
LIFTGATE (FET)
LIFTGLASS RELEASE RELAY
LOGIC
LR STOP/ TURN LAMP (FET)
M/E COOLANT PUMP RELAY
MASTER DRIVER WINDOW SIDE CONTROL DOOR SWITCH LOCK SWITCH
PARK LAMP RELAY
PASSENGER HEATED SEAT RELAY
PASSENGER SIDE DOOR LOCK SWITCH
REAR VIEW MULTI- CAMERA MEDIA DISPLAY INSIDE MIRROR MIRROR UNIT
RED WIRE
REVERSE LAMP RELAY
RF TURN LAMP (FET)
RIGHT LOW BEAM (FET)
ROOF AUTO- OPENING DIMMING PANEL INTERIOR MODULE MIRROR
ROOF OPENING PANEL SWITCH
RR STOP/ TURN LAMP (FET)
TO FUSE 27 (DIAGRAM 3 OF 5)
TO IGNITION SWITCH (DIAGRAM 4 OF 5)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (3 of 5) -> MASTER DRIVER WINDOW SIDE CONTROL DOOR SWITCH LOCK SWITCH
