Ford Escape II (2007-2012) dimmer gnd sw Wiring diagram
This page shows the only wiring diagram for the component.dimmer gnd sw, which is found in the car Ford Escape II (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dimmer gnd sw (1 of 1)
ACTIVE PARK ASSIST SWITCH
AMBIENT LIGHTING SWITCH
AUDIO/CLIMATE CONTROL SWITCH
BACKLIGHTING LED (FET) LOW
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLUE
BRN WIRE
CLOCKSPRING (TOP OF STEERING COLUMN)
DEFEAT
DIM DOME DOME SW AUTO LP DEFEAT ON OFF
DIMMER GND SW
FLOOR SHIFTER
FUSE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
ILLUMINATION DIMMER
LO BEAM PARK
LOGIC
MAIN LIGHT SWITCH
MESSAGE CENTER SWITCH
NCA WIRE
OFF AUTO 1
OFF DIM DEFEAT OFF
PARK ON
SMART JUNCTION BOX (SJB)
STEERING WHEEL/ SPEED CONTROL SWITCH
TRACTION CONTROL SWITCH
VIO/GRN WIRE
VIO/GRY WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit, hybrid -> DIMMER GND SW
