Ford Escape II (2007-2012) (dash panel to headlamp junction wiring harness, near Wiring diagram
This page shows the only wiring diagram for the component.(dash panel to headlamp junction wiring harness, near, which is found in the car Ford Escape II (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (dash panel to headlamp junction wiring harness, near (1 of 1)
ABS TEST CONNECTOR
AIR CONDITIONING CONTROL MODULE
AUTO DIMMING INTERIOR MIRROR
BATTERY
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BRAKE INJECTOR FLUID RELAY LEVEL SWITCH (LEFT REAR OF ENGINE COMPT)
BREAKOUT TO BATTERY JUNCTION BOX (BJB))
BRN WIRE
DRIVER DRIVER SIDE SIDE FRONT DOOR DOOR LOCK LOCK SWITCH UNIT
GRN WIRE
GRY WIRE
HARNESS, NEAR BREAKOUT TO BATTERY JUNCTION BOX (BJB))
JUNCTION BOX (BJB))
KEYPAD SWITCH ASSEMBLY
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT FRONT SIDE LAMP
LEFT HEAD- LAMP
LEFT HORN
LEFT REAR DOOR LOCK ACTUATOR
LIFTGATE GLASS AJAR SWITCH
LIFTGATE LOCK ACTUATOR
M/E COOLANT HEATER PUMP PUMP MOTOR MOTOR
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
MULTIMEDIA INSIDE MIRROR UNIT
NCA WIRE
NEAR BREAKOUT TO
PARKING AID MODULE (PAM)
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE FRONT DOOR LOCK UNIT
POWERTRAIN CONTROL MODULE (PCM)
REAR VIEW CAMERA DISPLAY MIRROR
REAR VIEW RIGHT REAR PARK CAMERA DOOR LOCK BRAKE ACTUATOR SWITCH
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT HEAD- LAMP
TRACTION BATTERY CONTROL MODULE
VIO WIRE
Go to component -> Ground distribution circuit, hybrid (1 of 3) -> (DASH PANEL TO HEADLAMP JUNCTION WIRING HARNESS, NEAR
