Ford Escape II (2007-2012) (between front storage tray lamp, breakout to Wiring diagram
This page shows the only wiring diagram for the component.(between front storage tray lamp, breakout to, which is found in the car Ford Escape II (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (between front storage tray lamp, breakout to (1 of 1)
AMBIENT LIGHTING MODULE (UNDER CENTER CONSOLE)
AMBIENT LIGHTING SWITCH
BIN LAMP)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
FRONT STORAGE TRAY LAMP
GRN WIRE
GRN/RED WIRE
LED SIG
LEFT CUPHOLDER LAMP
LEFT FRONT FOOTWELL LAMP
LEFT REAR FOOTWELL LAMP
ORG/ WIRE
RED WIRE
RIGHT CUPHOLDER LAMP
RIGHT FRONT FOOTWELL LAMP
RIGHT REAR FOOTWELL LAMP
RTN
STORAGE BIN LAMP
VIO/GRY WIRE
VPWR
Go to component -> Courtesy lamps circuit, except hybrid (2 of 2) -> (BETWEEN FRONT STORAGE TRAY LAMP, BREAKOUT TO
