Ford Escape II (2007-2012) audio/climate control switch Wiring diagrams
This page contains all the electrical diagrams for the component. audio/climate control switch, in which he is found in the car Ford Escape II (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram audio/climate control switch (1 of 2)
ACTIVE PARK ASSIST SWITCH
AMBIENT LIGHTING SWITCH
AUDIO/CLIMATE CONTROL SWITCH
AUTO ON
BACK- LIGHTING
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLUE
BRN WIRE
CLOCKSPRING (STEERING COLUMN)
DEFEAT
DEFEAT OFF DIM
DIM SW GND
DIMMER SW
DOME DOME DEFEAT LP
FLOOR SHIFTER
FUSE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
ILLUMINATION DIMMER
LED (FET)
LO BEAM PARK
LOGIC (CENTER OF DASH)
MAIN LIGHT SWITCH
MESSAGE CENTER SWITCH
NCA WIRE
OFF
OFF AUTO 1
PARK LOW ON OFF
SMART JUNCTION BOX (SJB)
STEERING WHEEL/ SPEED CONTROL SWITCH
TRACTION CONTROL SWITCH
VIO/GRN WIRE
VIO/GRY WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit, except hybrid -> AUDIO/CLIMATE CONTROL SWITCH
Wiring diagram audio/climate control switch (2 of 2)
ACTIVE PARK ASSIST SWITCH
AMBIENT LIGHTING SWITCH
AUDIO/CLIMATE CONTROL SWITCH
BACKLIGHTING LED (FET) LOW
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLUE
BRN WIRE
CLOCKSPRING (TOP OF STEERING COLUMN)
DEFEAT
DIM DOME DOME SW AUTO LP DEFEAT ON OFF
DIMMER GND SW
FLOOR SHIFTER
FUSE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
ILLUMINATION DIMMER
LO BEAM PARK
LOGIC
MAIN LIGHT SWITCH
MESSAGE CENTER SWITCH
NCA WIRE
OFF AUTO 1
OFF DIM DEFEAT OFF
PARK ON
SMART JUNCTION BOX (SJB)
STEERING WHEEL/ SPEED CONTROL SWITCH
TRACTION CONTROL SWITCH
VIO/GRN WIRE
VIO/GRY WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit, hybrid -> AUDIO/CLIMATE CONTROL SWITCH
