Ford Escape II (2007-2012) 39 49 37 26 27 23 69 70 53 25 10 24 cht sigrtn Wiring diagram
This page shows the only wiring diagram for the component.39 49 37 26 27 23 69 70 53 25 10 24 cht sigrtn, which is found in the car Ford Escape II (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 39 49 37 26 27 23 69 70 53 25 10 24 cht sigrtn (1 of 1)
19 34 44 50 46 11 45 43 10 39 1 25 36 16 49 29 41 40 48 TFT LPC VFS
39 49 37 26 27 23 69 70 53 25 10 24 CHT SIGRTN
40 41 56 47 70 MAF MAFRTN SIGRTNC IAT POWER GND
67 38 13 62 VPWR PCMRC BPP KAPWR
BATTERY JUNCTION BOX (BJB) (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
ENGINE CONTROLS SYSTEM
FUSE 28
FUSE 29
FUSE 5
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEATED OXYGEN
HOT AT ALL TIMES
HTR-22
INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR (REAR OF ENGINE)
MASS AIR FLOW/
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM) (CENTER REAR OF FIREWALL)
SOL PWR TCC VFS SSE ON/OFF SOL
TCS
TFT SIGRTN
TRS TRS/OSS VPWR OSS TSS/OSS/TR GND TSS HTR 12
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> 3.0l, a/t circuit (2 of 2) -> 39 49 37 26 27 23 69 70 53 25 10 24 CHT SIGRTN
