Ford Escape I facelift (2004-2007) Parking assistant circuit

BLK WIRE BLK/PNK WIRE BRN/PNK WIRE COMPUTER DATA LINES SYSTEM DK BLU/YEL WIRE DK GRN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE FUSE 29 GROUND HOT IN RUN AND START INNER LEFT SIGNAL INNER RIGHT SIGNAL ISO BUS LEFT INNER PARKING AID SENSOR LEFT OUTER PARKING AID SENSOR LT BLU WIRE LT BLU/WHT WIRE OFF ON ON/OFF SIG ORG/ WIRE OUTER LEFT SIGNAL OUTER RIGHT SIGNAL PARK AID ENABLE PARK AID SPEAKER (-) PARKING AID DISABLE SWITCH PARKING AID MODULE (PAM) PARKING AID SPEAKER RED WIRE RED/BLK WIRE REF VOLTAGE REVERSE LAMPS RELAY RIGHT INNER PARKING AID SENSOR RIGHT OUTER PARKING AID SENSOR SIG RETURN SMART JUNCTION BOX (SJB) VIO WIRE VIO/ORG WIRE VPWR WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE
