Courtesy lamps circuit, without roof opening panel except hybrid for Ford Escape I facelift (2004-2007)
Courtesy lamps circuit, without roof opening panel except hybrid
AJAR
BATTERY JUNCTION BOX (BJB)
BATTERY SAVER
BLK WIRE
BLK/WHT WIRE
CARGO LAMP
DK BLU WIRE
DOOR ON
DRIVER SIDE FRONT DOOR LOCK UNIT
FRONT INTERIOR LAMP
FUSE 2
FUSE 3
HOT AT ALL TIMES
INTERIOR DOME LAMPS
LEFT REAR DOOR LOCK ACTUATOR
LEFT VANITY MIRROR LAMP
LF DOOR AJAR
LR DOOR AJAR
LT GRN/BLK WIRE
LT GRN/YEL WIRE
OFF
OFF ON OFF
ON OFF
PASSENGER SIDE FRONT DOOR LOCK UNIT
PNK WIRE
PNK/LT BLU WIRE
RF DOOR AJAR
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT VANITY MIRROR LAMP
RR DOOR AJAR
SJB LOGIC
SMART JUNCTION BOX (SJB)
VBATT
VIO/LT GRN WIRE
VIO/ORG WIRE
WHT WIRE
YEL/WHT WIRE
