Courtesy lamps circuit, hybrid for Ford Escape I facelift (2004-2007)

Courtesy lamps circuit, hybrid

Get access

AJAR BATTERY JUNCTION BATTERY SAVER BLK WIRE BLK/WHT WIRE BRAKE SYSTEM CONTROL MODULE CARGO LAMP DK BLU WIRE DOOR ON DRIVER SIDE FRONT DOOR LOCK UNIT FRONT INTERIOR LAMP FUSE 12 BOX (BJB) FUSE 13 HOT AT ALL TIMES INTERIOR DOME LAMPS LEFT REAR DOOR LOCK ACTUATOR LF DOOR AJAR LR DOOR AJAR LT GRN/BLK WIRE LT GRN/YEL WIRE OFF OFF ON OFF ON OFF PASSENGER SIDE FRONT DOOR LOCK UNIT PNK WIRE PNK/LT BLU WIRE RF DOOR AJAR RIGHT REAR DOOR LOCK ACTUATOR RR DOOR AJAR SJB LOGIC SMART JUNCTION BOX (SJB) VBATT VIO/LT GRN WIRE VIO/ORG WIRE WHT WIRE YEL/WHT WIRE
