Exterior lamps & trailer connector circuit, hybrid for Ford Escape I facelift (2004-2007)

4) HEADLAMPS BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/ WHT WIRE BLK/WHT WIRE BPP INPUT VBATT BRN WIRE FUSE 12 FUSE 13 FUSE 3 FUSE 6 GROUND HAZARD FLASHER SWITCH HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT FRONT PARK/ TURN LAMP LEFT TURN LEFT TURN SIG LIGHT SWITCH 1) AUTO 2) OFF 3) PARK LOGIC RIGHT TURN LOM LOW BEAM SW LT BLU/ORG WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/ORG WIRE LT GRN/RED WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE OFF PARK PARK LAMP RELAY RED/ LT GRN WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT PARK/ TURN LAMP RIGHT LEFT RIGHT TURN SIG SMART JUNCTION BOX (SJB) TURN VBATT VBATT VPWR VPWR VPWR VPWR VREF WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE YEL/WHT WIRE

BLK WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE HIGH MOUNTED STOPLAMP LEFT LICENSE PLATE LAMP LEFT REAR PARK/ STOP LAMP LEFT REAR TURN LAMP LT BLU/ORG WIRE LT GRN WIRE LT GRN/RED WIRE LT GRN/WHT WIRE PARK POWERTRAIN CONTROL MODULE (PCM) RED/LT GRN WIRE RIGHT LICENSE PLATE LAMP RIGHT REAR PARK/ STOP LAMP RIGHT REAR TURN LAMP TURN WHT/LT BLU WIRE
