Back-up lamps circuit, a/t except hybrid for Ford Escape I facelift (2004-2007)
Back-up lamps circuit, a/t except hybrid
15 12 MS CAN- MS CAN+ MS CAN-
3.0L
BLK WIRE
BLK/PNK WIRE
COMPUTER DATA LINES SYSTEM
ELECTROCHROMIC INSIDE MIRROR UNIT
FUSE 29
GRY/RED WIRE
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT REVERSING LAMP RIGHT REVERSING LAMP
LOGIC
LT GRN WIRE
MS CAN +
PARKING AID MODULE
PNK/ORG WIRE
POWERTRAIN CONTROL MODULE
REVERSING LAMPS RELAY
SMART JUNCTION BOX
TRANSMISSION RANGE SENSOR
WHT WIRE
WHT/ORG WIRE
