2.3l, cooling fan circuit, except hybrid for Ford Escape I facelift (2004-2007)
2.3l, cooling fan circuit, except hybrid
41 33 SIGRTNE CHT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/LT GRN WIRE
BLK/YEL WIRE
COOLING FAN RELAY
CYLINDER HEAD TEMPERATURE SENSOR
DK BLU WIRE
DUAL PRESSURE SWITCH
ENGINE CONTROLS SYSTEM
ENGINE COOLING FAN MOTOR 1
ENGINE COOLING FAN MOTOR 2
FUSE 22 FUSE 24
FUSE 5
GRY WIRE
GRY/RED WIRE
HI FAN CTRL ACPSW
HIGH SPEED FAN CONTROL RELAY 1
HOT AT ALL TIMES
HOT IN RUN OR START
LOW FAN CTRL COOLING FAN CTRL
LOW SPEED FAN CONTROL RELAY
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/VIO WIRE
ORG/ WIRE
PCM POWER DIODE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/ORG WIRE
SMART JUNCTION BOX (SJB)
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/LT GRN WIRE
