Passive anti-theft circuit, hybrid for Ford Escape I facelift (2004-2007)

Passive anti-theft circuit, hybrid

Get access

1 2 3 4 RF_PWR RF_GND TX_SIG RX_SIG 31 42 TX_OUT RX_DATA BLK WIRE BLK/WHT WIRE BRN/ORG WIRE HOT IN START OR RUN PASSIVE ANTI-THEFT TRANSCEIVER PCM POWER DIODE POWERTRAIN CONTROL MODULE (PCM) RED/BLK WIRE SMART JUNCTION BOX (SJB) FUSE 5 VIO WIRE WHT WIRE WHT/VIO WIRE
