Passive anti-theft circuit, except hybrid for Ford Escape I facelift (2004-2007)
Passive anti-theft circuit, except hybrid
1 2 3 4 VPWR GND TX RX
2 31 42 STRT OUT TX RX
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/WHT WIRE
BRN/ORG WIRE
DK BLU WIRE
DK BLU/ORG WIRE
HOT IN START OR RUN
LT BLU WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER
PCM POWER DIODE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/BLK WIRE
SMART JUNCTION BOX (SJB) FUSE 5
STARTER RELAY
STARTER RELAY DIODE
VIO WIRE
WHT WIRE
WHT/VIO WIRE
