Ford Escape I facelift (2004-2007) pcm power relay powertrain control module Wiring diagram
This page shows the only wiring diagram for the component.pcm power relay powertrain control module, which is found in the car Ford Escape I facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pcm power relay powertrain control module (1 of 1)
7 SPEAKER 4 SPEAKER
ACCESSORY DELAY RELAY
AUDIO UNIT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
DK GRN WIRE
DK GRN/ORG WIRE
FLOOR SHIFTER
FROM FUSE 15 (BJB) (DIAGRAM 2 OF 4)
FROM FUSE 22 (BJB) (DIAGRAM 1 OF 4)
FROM FUSE 30 (BJB) (DIAGRAM 1 OF 4)
FRONT CIGAR LIGHTER
FUSE 11
FUSE 12
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 23
FUSE 24 FUSE 22
FUSE 4
FUSE 5
IGNITION SWITCH
INSTRUMENT CLUSTER
INTELLIGENT TORQUE COUPLING (ITCC) MODULE
KEY-IN IGNITION SWITCH
LEFT REAR WINDOW ADJUST SWITCH RIGHT REAR WINDOW ADJUST SWITCH
LOCK OFF
LOCK SOLENOID
LOGIC
LOGIC KEY IN IGNITION
LT BLU WIRE
LT GRN WIRE
MS-CAN/ACP GATEWAY MODULE (W/ NAVIGATION)
NOT USED NOT USED
ORG/ WIRE
PASSENGER SIDE WINDOW ADJUST SWITCH PASSENGER SIDE DOOR LOCK SWITCH
PASSIVE ANTI-THEFT TRANSCEIVER
PCM POWER DIODE
PCM POWER RELAY POWERTRAIN CONTROL MODULE
PNK WIRE
POWERTRAIN CONTROL MODULE
RED WIRE
RELAY
RUN WIRE
RUN/
RUN/ ACCESSORY RELAY
SMART JUNCTION BOX (SJB)
SUBWOOFER AMPLIFIER
TAN WIRE
TO FUSE 21 (SJB) (DIAGRAM 4 OF 4)
TO FUSE 28 (SJB) (DIAGRAM 4 OF 4)
VIO WIRE
VPWR
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (3 of 4) -> PCM POWER RELAY POWERTRAIN CONTROL MODULE
