Ford Escape I facelift (2004-2007) logic bpp input Wiring diagram
This page shows the only wiring diagram for the component.logic bpp input, which is found in the car Ford Escape I facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram logic bpp input (1 of 1)
BLK WIRE
BRAKE PEDAL POSITION SWITCH
DK GRN WIRE
DK GRN/ORG WIRE
FLOOR SHIFTER
FUSE 4
FUSE 6
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER
KEY IN IGNITION
KEY-IN IGN
LOCK
LOGIC BPP INPUT
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK RANGE
PNK WIRE
RED WIRE
REDUNDANT PARK SWITCH STATUS INPUT
SHIFT LOCK SOLENOID
SHIFT-LOCK SOL
SMART JUNCTION BOX (SJB)
Go to component -> Shift interlock circuit, hybrid -> LOGIC BPP INPUT
