Ford Escape I facelift (2004-2007) integrated control panel wiring diagram

AIR BAG DEACTIVATION WARNING IND BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAN+ CAN- FCS FEED FCS RTN PASS SAB FEED PASS SAB RTN SEAT TRK FEED DATA LINK CONNECTOR (DLC) DK GRN/WHT WIRE DRIVER SAFETY BELT RETRACTOR PRETENSIONER DRV BUCKLE SW IN PASS BUCKLE SW IN DRVR PRETENS FEED DRVR PRETENS RTN PASS PRETENS FEED PASS PRETENS RTN FUSE 33 GRN WIRE GRY/ORG WIRE GRY/WHT WIRE HOT IN RUN OR START INSTRUMENT CLUSTER INTEGRATED CONTROL PANEL ISO VPWR LATE PRODUCTION LEFT SEAT POSITION SENSOR LEFT SIDE IMPACT SENSOR LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NCA WIRE ORG/LT GRN WIRE PAD LAMP PASSENGER SAFETY BELT RETRACTOR PRETENSIONER PNK/BLK WIRE PNK/ORG WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE RED/PNK WIRE RED/WHT WIRE RESTRAINTS CONTROL MODULE RIGHT SIDE IMPACT SENSOR RIL RIL GROUND SEAT BELT BUCKLE SENSOR DRIVER SIG SEAT BELT BUCKLE SENSOR PASSENGER SIG SIDE AIR BAG MODULE DRIVER SIDE AIR BAG MODULE PASSENGER SMART JUNCTION BOX TAN/LT BLU WIRE TONE VIO WIRE VIO/LT GRN WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/WHT WIRE
