Ford Escape I facelift (2004-2007) hot in run smart junction box Wiring diagram
This page shows the only wiring diagram for the component.hot in run smart junction box, which is found in the car Ford Escape I facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in run smart junction box (1 of 1)
BATTERY JUNCTION BOX
BLK WIRE
BLK/LT BLU WIRE
BRN/LT BLU WIRE
DRIVER SIDE FRONT HEATED SEAT MODULE
DRIVER SIDE SEAT HEATER SWITCH
FUSE 10
FUSE 35
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN SMART JUNCTION BOX
LEFT FRONT SEAT CUSHION HEATER
ORG/ WIRE
PASSENGER SIDE FRONT HEATED SEAT MODULE
PASSENGER SIDE SEAT HEATER SEAT HEATER SWITCH SWITCH
RED WIRE
RED/BLK WIRE
VIO/LT BLU WIRE
YEL/LT BLU WIRE
Go to component -> Heated seats circuit -> HOT IN RUN SMART JUNCTION BOX
