Ford Escape I facelift (2004-2007) defroster on indicator Wiring diagram
This page shows the only wiring diagram for the component.defroster on indicator, which is found in the car Ford Escape I facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defroster on indicator (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BRN WIRE
DEFROSTER ON INDICATOR
DK BLU WIRE
DK GRN WIRE
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
FUSE 10
FUSE 23
HOT AT ALL TIMES
LT BLU WIRE
NCA WIRE
OFF
ORG/ WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
REAR WINDOW DEFROST GRID
REAR WINDOW DEFROST RELAY
REAR WINDOW DEFROST SWITCH
RED WIRE
SJB LOGIC
SMART JUNCTION BOX (SJB)
SWITCH ILLUM.
VIO WIRE
Go to component -> Defoggers circuit, except hybrid -> DEFROSTER ON INDICATOR
